Details:
New: Artifical Horizon Display
We’re pleased to introduce the Eagle Tree OSD Pro.The OSD Pro displays all the key information about your model’s status, and has many advanced features such as voice alerts, high resolution raster graphics, a new airplane icon “RADAR” synthetic map, “Return to Home,” Artificial Horizon display, and waypoints within visual range.
How it Works
The OSD Pro is a powerful, modular, fully configurable Video/Audio On-Screen Display (OSD) device, providing graphics, voice announcements, alarms, acoustic variometer with total energy compensation, Home Arrow, Return to Home, Failsafe, "Radar" is the airplane icon on the screen, waypoints, a flight simulator for testing, and many other features.
The information displayed can be as simple or advanced as you like, depending on how you configure the display, and on which optional Eagle Tree sensor you connect.
All parameters available with our eLogger V4 and Data Recorders + optional sensors will be supported for display on the OSD Pro.
How it Works
The OSD Pro is a powerful, modular, fully configurable Video/Audio On-Screen Display (OSD) device, providing graphics, voice announcements, alarms, acoustic variometer with total energy compensation, Home Arrow, Return to Home, Failsafe, "Radar" is the airplane icon on the screen, waypoints, a flight simulator for testing, and many other features.
The information displayed can be as simple or advanced as you like, depending on how you configure the display, and on which optional Eagle Tree sensor you connect.
All parameters available with our eLogger V4 and Data Recorders + optional sensors will be supported for display on the OSD Pro.
Here are some examples:
* GPS Parameters (Distance to Home, Home Arrow, GPS Altitude, Ground Speed, Course, and more)
* Electrical Parameters (Pack Volts, Amperage, RX Volts, Servo Current, Milliamp-Hours, Watts)
* Performance Parameters (Airspeed, Barometric Altitude, Climb Rate, Variometer, Temperatures, RPM, G-Force, EGT, Jet ECU Status, servo positions)
* Receiver Health (Dropped Frames, Antenna Fades, Missed Packets – requires Spektrum or JR FlightLog compatible Receiver)
* Call Sign, and many more
New: Artifical Horizon Display
When you connect the FMA Direct™ CPD-4™ X/Y horizon sensor (either with or without the FMA™ stabilization Computer), an artifical horizon line can be displayed on the video screen. Click here for information on how to connect the FMA Direct sensor to the OSD Pro system.
Instruction Manual: Click Me!
See the video below for an example of the AHI display tracking the horizon:
Click here to see a diagram on how to connect the OSD Pro.
Package Includes:
- eLogger V4 80 volts 150A current sensor with wire leads
- Video OSD Pro Expander
- 10 Hz GPS Expander
– If you need more information, use these Eagle Tree Systems resources –
E-mail: sales@eagletreesystems.com Web Site: www.eagletreesystems.com/Support/support.html Eagle Tree Systems 4957 LAKEMONT BLVD SE BELLEVUE, WA 98006 Phone: 425-614-0450
