The Oracle is a must to have tool for any video reception application, mainly in situations where the transmitter is always moving around. This device will eliminate to almost zero video drops and give you the video quality you are looking for.
The Oracle video diversity controller is used to bridge two wireless video receivers together. Twin receivers can be used to create RF diversity arrangements, which help reduce multi-path nuisances, as well as allow for other signal improving techniques.
In other words, Oracle can be used to create an effective spatial diversity system using your existing A/V equipment. This configuration involves placing the antennas (from two receivers) at slightly different locations. As little as a few inches apart is enough to offer noticeable signal improvement. Oracle can just as easily be used in frequency and polarization diversity applications too.
Oracle employs a sophisticated real-time video analysis technique. Simply put, the video display is switched to the best receiver based on its video quality. This effective method means that any composite (NTSC or PAL) video receiver can be used. Because connections to the receiver's internal electronic circuitry are NOT required, the installation is essentially plug-n-go
By avoiding the need for special integrated A/V receivers, YOU get to choose the video gear that you want to use. Best of all, you can use A/V equipment that operates on any of the popular RF bands (for example: 900Mhz, 1.2GHz or 2.4Ghz). Finally, a truly universal solution is here! Here is basicly how Oracle works: the two receivers send video signal to Oracle, the strongest video signal is selected to you video monitor or video glasses. In other words, Oracle selects which receiver has the best and strongest video reception. This selection or switching process between the two receivers happens so fast causing zero video or audio interruption at all.
Manual: CLICK HERE
- Universal wireless video receiver compatibility (NTSC or PAL).
- Two channel audio support (stereo audio or voice/data).
- Very high bandwidth. No A/V signal degradation.
- Dual video outputs.
- Buffered audio output.
- No special installation requirements (uses standard RCA connectors).
- Low voltage alarm.
- DC Power Cord included (center pin positive). Operates on 6VDC to 14VDC (90mA typical).
- Small size, 6.0 inch x 4.5 inch x 2.3 inch.
